Forklift Hydraulic Pumps

Forklift Hydraulic Pump - Usually used in hydraulic drive systems; hydraulic pumps could be either hydrostatic or hydrodynamic.

Hydrodynamic pumps could be considered fixed displacement pumps. This means the flow throughout the pump for every pump rotation cannot be adjusted. Hydrodynamic pumps could likewise be variable displacement pumps. These types have a much more complicated construction that means the displacement is capable of being adjusted. On the other hand, hydrostatic pumps are positive displacement pumps.

Nearly all pumps are working within open systems. Normally, the pump draws oil from a reservoir at atmospheric pressure. In order for this particular method to run efficiently, it is essential that there are no cavitations occurring at the suction side of the pump. So as to enable this to function properly, the connection of the suction side of the pump is bigger in diameter compared to the connection of the pressure side. Where multi pump assemblies are concerned, the suction connection of the pump is usually combined. A general alternative is to have free flow to the pump, which means the pressure at the pump inlet is a minimum of 0.8 bars and the body of the pump is often within open connection with the suction portion of the pump.

In the cases of a closed system, it is acceptable for both sides of the pump to be at high pressure. Usually in these situations, the reservoir is pressurized with 6-20 bars of boost pressure. In the instance of closed loop systems, normally axial piston pumps are utilized. For the reason that both sides are pressurized, the pump body needs a separate leakage connection.


Click to Download the pdf
